How To Make RC Model Airplane Fun-Fly Style. DIY RC Airplane With Brushless motor

How to make slow flying and acrobatic fun fly sytle RC airplane.
The Fun-Fly model aircraft can fly at very low speeds. It can maneuver in short distance and perform acrobatic maneuvers in series. Very short distance is enough for take off.

INFORMATION: The Foamboard is made of foam and the outside is paper-covered. It is lightweight, robust and easy to cut. Easily bonded with hot silicone.

Necessary Materials:

2205 2000-2600KV Brushless Motor: https://s.click.aliexpress.com/e/_DCZNe5D
Propellers (6040): https://s.click.aliexpress.com/e/_DdHiK0r
30A Brushless ESC: https://s.click.aliexpress.com/e/_DdC5cpH
11.1V 1000-1300Mah LiPo battery (3S): https://s.click.aliexpress.com/e/_DEnwHph
OR 11.1V 1300 mAh: https://s.click.aliexpress.com/e/_Dd8cw0L
2pcs 35-40mm Wheel: https://s.click.aliexpress.com/e/_DBKUPzd
Pushrods & landing gear rod: https://s.click.aliexpress.com/e/_DENblcj
4 pieces horns: https://s.click.aliexpress.com/e/_DDCKYlh
4 or 6 channel radio control system: Radio Control: https://s.click.aliexpress.com/e/_DCPHEVN OR https://tr.banggood.com/custlink/vvGEUUB1Tq
4 micro servos (may be 9gr servos): https://s.click.aliexpress.com/e/_Dm9dNHh
Gold Connectors 3.5mm (Motor & ESC connections): https://s.click.aliexpress.com/e/_DmxurfH
Wheel stopper: https://s.click.aliexpress.com/e/_DCcQYir
Y extension cable: https://s.click.aliexpress.com/e/_DegReWn
L type nylon clevis keper clip: https://s.click.aliexpress.com/e/_DkuA2an
Adjustable Linkage stopper (Easy Link): https://s.click.aliexpress.com/e/_Dkvqb51
Fastener strip : https://s.click.aliexpress.com/e/_DnNJGjd

Lipo Battery Charger: https://s.click.aliexpress.com/e/_DF5pqlz OR
https://s.click.aliexpress.com/e/_DlwNzmj OR

Hot melt Glue Gun: https://s.click.aliexpress.com/e/_DkCDXLd OR
https://s.click.aliexpress.com/e/_DnDleen OR https://s.click.aliexpress.com/e/_Dl2EcLt

Technicial Specifications:
Lenght: 680 mm
Wing span: 665mm
Flight weight: About 490 g
Center of gravity: 5.5-6 cm from the front of the wing
Required control system: Min. 4 channels, 4 micro servos
Suitable battery: 11.1V 1000Mah – 1300Mah Lipo battery
Suitable motor: 2205 Brushless (2000-2600KV)
Suitable propeller: 2 Blade 6×4 or 3 Blde 5×4.5
